Intel® 6th/7th-Gen Quad Core Xeon/ Core i7/i5/i3 CPU w/ 4 x GbE/ 4 x ISO COM/ 2 x DP/ VGA/
4 USB 3.0 Fast Expansible Slot 9-36V Fanless Computer
產品特色
SYSTEM
Processor
Intel® Xeon E3-1268L v5 (8M, cache 2.4~3.4GHz)
Intel® Gen6 Core i7-6700TE (8M Cache 2.4GHz up to 3.4GHz)
Intel® Gen6 Core i5-6500TE (6M Cache 2.3GHz up to 3.3GHz)
Intel® Gen6 Core i3-6100TE (4M Cache 2.7GHz)
Chipset
Intel® Q170 for Intel® 6th-Gen Skylake-S Core-i series
Intel® C236 for Xeon Quad Core E3-1268L v5 (optional)
Memory
2 x DDR4 2133 MHz SO-DIMM up to 32GB
Watchdog
1 ~255 Level Reset
TPM
2.0
GRAPHICS
Graphics Engine
Intel® HD Graphics 530
DirectX Video Acceleration (DXVA) for Accelerating Video Processing – Full AVC/VC1/MPEG2 HW Decode Supports DirectX 11/10.1/10/9 and OpenGL 4.0
DisplayPort
2
VGA
1
(Triple Independent Display)
Resolution
Max Resolution (VGA): 1920×1200@ 60 Hz
Max Resolution (DP): 4096×2304@ 60 Hz
AUDIO
Line-out
1
Mic-in
1
Line-in
Optional
ETHERNET
LAN Chipset
3 x Intel® i210-AT and 1 x i219LM (iAMT9.5 w/ i5, i7 only) Gb/s Ethernet Controllers Onboard Support PXE and WOL
LAN
4 x RJ45 Ports
PoE
Optional for 4 x PoE 15.4W
I/O
Serial Port
4 x RS 232/422/485 w/1.5KVms isolation
(Auto Direction Control)
USB
4 x USB 3.0 Ports
DIO
8 x GPI and 4 x GPO connector w/1.5KVms isolation
SIM Socket
2 x SIM Card Socket for 3G/LTE
STORAGE
Type
2 x 2.5” Drive Bay for SATA Type HDD/SSD RAID 0, 1, 5 1 x SATA DOM
EXPANSION
Mini PCI Express
3 Full and 1 Half Mini-PCIe Slot
FES Expansion
Support PCI-E Bus, USB Bus, SMBus, GPIO, and SATA Bus (Customized for Customer without NRE charge)
POWER
Power Input
9V – 36V DC Power Input
Power Protection
Automatics Recovery Short Circuit Protection
Smart Ignition
Vehicle Power Ignition for Variety Vehicle
Power-off Delay Control
Power off Delay Time Setting by BIOS and Software
Backup Battery Solution
Internal Battery Kit for 10 Mins Operating (Optional)
MECHANICAL
Dimensions
240(L) x 226(W) x 79(H) mm
Weight
3860g (Barebone)
Construction
Aluminum Alloy
Mounting
Wall-mount
ENVIRONMENT
Relative Humidity
10% RH – 90% RH (non-condensing)
Operating Temp.
-40°C ~ 70°C (Default CPU 35Watt), ambient w/ 0.6m/s airflow
Storage Temp.
-40°C ~ 80°C
Vibration & Shock
IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis with SSD
MIL-STD-810G, Method 514.6, Procedure I, Category
Shock Operating: MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi-trailers=15G (11ms) with SSD
CERTIFICATION
Certification
CE, FCC Class A, E-Mark
ORDERING INFORMATION
Model No.
ABOX-5000P-i7 Optional for i5/i3/C1
Description
Intel® 6th/7th-Gen Quad Core Xeon/ Core i7/i5/i3 CPU w/ 4 GbE/ 4 ISO COM/ 2 DP/ VGA/ 4 USB 3.0 Fast Expansible Slot/ 9-36V Fanless Computer
State of Origin
Made in Taiwan
